Portable Oil Coalescer Separator

The Oil Coalescer Separator was designed to remove moisture and particulate contamination from oil using the principles of filtration and coalescing/separation.

• Extends turbine oil life
• Reduces maintenance
• Increases bearing life
• Easy operation
• Economically priced
• Protects system’s components from corrosion

• Compact design
• ASME Code vessel design
• Highly efficient pre-filter
• Clean and dirty sampling ports
• Basket strainer protects pump
• Differential pressure switch and gauge
• Sight glass for visual examination
• Automatic float and water discharge valve for continuous operation
• CSA (Canadian Standards Assoc.) approval available
• Swing bolt cover design allows for easy element change out

Get more info or reserve your Portable Unit Today!

• Contamination removal – The Oil Coalescer Separator removes particulates using a B6=200 pleated polyester cartridge. Ratings were established by
• Multipass Test ISO 4572. Element is 99.5% efficient.
• Water Removal – The Oil Coalescer Separator removes free and emulsified water to less than 25 PPM and reduces total water content to less than 150 PPM.
• Tested on four major brands of turbine lube oil
• Results based on an influent with 5000 PPM water
• Lab services available.
